    Workshop Motorized Platform Cart ODM Motorized Rail Cart

    Ask Lasest Price
    Brand Name : Dowellcrane
    Model Number : KPC KPDS KPDZ KPJ KPT KPX
    Certification : CE ISO
    Price :
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 20000sets/years
    Delivery Time : 20 work days
    • Product Details
    • Company Profile

    Workshop Motorized Platform Cart ODM Motorized Rail Cart

    workshop motorized platform cart odm transfer cart


    Description


    workshop motorized platform cart odm transfer cart is an alternative transfer cart for rail transfer cars. It overcomes many inconvenience of rail-type electric transfer carts. The trackless electric transfer carts can finish free-turning without rail in the workshop and workshop. There is no need to lay rails, so it does not affect traffic, does not hinder production, and the flat car is more flexible, the operation is more humanized.


    Features Of Transfer Cart


    1. It is not restricted by the track and can travel on the ground.It can turn 360 degrees.
    2. Suitable for all kinds of environments.It can be used indoors or outdoors in high temperature explosion-proof and other environments.
    3. Suitable for long distance operation.
    4. Customized for you.Custom table size, operating speed,load,etc.Meet your requirements.
    5. Equipped with safety warning and automatic stop device.
    Product Paramenters
    Model
    KPX-2t
    KPX-20t
    KPX-50t
    KPX-100t
    KPX-150t
    Rated Load(t)
    2
    20
    50
    100
    150
    TableSize(mm)
    Length(L)
    2000
    4000
    5500
    6500
    10000
    Width(W)
    1500
    2000
    2500
    2800
    3000
    Heigth(H)
    150
    550
    650
    850
    1200
    Wheel Base(mm)
    1200
    2800
    4200
    4900
    7000
    Rail Inner Gauge(mm)
    1200
    1435
    1435
    2000
    2000
    Wheel Diameter(mm)
    270
    350
    500
    600
    600
    Wheel Quantity
    4
    4
    4
    4
    8
    Ground Clearance(mm)
    50
    50
    50
    75
    75
    Running Speed(mm)
    25
    20
    20
    20
    18
    Motor Power(kw)
    0.8
    2.5
    5.5
    11
    15
    Max Wheel Load(KN)
    14.4
    77.7
    174
    343.8
    265.2
    Reference Weight(t)
    2.3
    5.5
    7.6
    13.9
    26
    Recommended Rail Model
    P15
    P24
    P43
    QU100
    QU100

    Transfer cart parts
