    32t Lifting Inversion Electric Hoist Overhead Crane Box Type

    Ask Lasest Price
    Brand Name : Dowellcrane
    Model Number : LDP Single Girder Overhead Crane
    Certification : SGS IOS CE
    Price :
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 20000 Sets per Year
    Delivery Time : 15 work days
    • Product Details
    • Company Profile

    32t Lifting Inversion Electric Hoist Overhead Crane Box Type

    32t ce certificated lifting inversion electric hoist overhead crane

    Product Description

    32t ce certificated lifting inversion electric hoist overhead crane is designed as light type lifting equipment according to China standard. It is equipped with the features of reasonable structure,max.lifting height, strong rigidity of whole set. This crane equips with wire rope electric hoist to lift different cargoes, its capacity can vary 1-20ton and span 7.5-31.5m, working class A3-A4 according to ISO standard. The standard working environment temperature is from -20 to 40°C.
    This kind of crane is widely used in factory, warehouse, stuff yard to lift goods, forbidden to use in flammable, explosive and corrosive environment. This single girder overhead crane is operated by pendent control or remote control.

    Safe devices

    1.Weight overload protection device
    2.Top quality durable polyurethane buffer
    3.Crane traveling limit switch
    4.Low voltage protection function
    5.Emergency stop system
    6.Current overload protection function

    Features

    32t ce certificated lifting inversion electric hoist overhead crane can effectively save plant space and investment. The cost and unique structure of the walking are your best choice.
    1.Higher working efficiency
    2.Easy installation and operation
    3.Good design, Strong rigidity
    4.Smoothly moving, Effectively braking
    5.low energy consumption, strong rigidity, light weight

    Inquiry notice ! ! !
    If you want to inquire about our overhead crane , please confirm with us the details as below. Then we will quote you a suitable price more quickly.
    1. Lift capacity (3t 5t 10t or others) ?
    2. Span (3m 5m 9m or others) ?
    3. Lift height (Warehouse width) ?
    4. Power supply in your local (380V/50HZ/3Phase or others) ?
    5. Nearest port ?
    6. What kind of goods will this crane lift ?

    overhead crane parameters

    Span
    S(m)
    7.5
    10.5
    13.5
    16.5
    19.5
    22.5
    25.5
    28.5
    Lifting height
    m
    9
    9
    9
    9
    9
    9
    9
    9
    Lifting speed
    m/min
    7
    7
    7
    7
    7
    7
    7
    7
    Trolley speed
    m/min
    20
    20
    20
    20
    20
    20
    20
    20
    Crane speed
    m/min
    20
    20
    20
    20
    20
    20
    20
    20
    Lifting motor
    kw
    13
    13
    13
    13
    13
    13
    13
    13
    Trolley motor
    kw
    0.8
    0.8
    0.8
    0.8
    0.8
    0.8
    0.8
    0.8
    Total weight
    t
    3.26
    3.76
    4.4
    5.17
    5.92
    7.48
    9.71
    14.05
    Max Wheel Load
    KN
    51.3
    55.3
    58.4
    61.3
    63.9
    68.2
    74.2
    85.4
    Track
    P24
    P24
    P24
    P24
    P24
    P24
    P24
    P24
    Main dimension
    mm
    7.5
    10.5
    13.5
    16.5
    19.5
    22.5
    25.5
    28.5
    Rail top to main top
    H1
    720
    720
    820
    875
    875
    925
    1100
    1200
    Rail top to hook centre
    H2
    1850
    1850
    1850
    1900
    1940
    2000
    1920
    1920
    Wheel base
    W
    2000
    2000
    2000
    2500
    2500
    3000
    3500
    4000
    Crane width
    B
    2500
    2500
    2500
    3000
    3000
    3500
    4000
    4700
    Hook left limitation
    S1
    1293
    1293
    1293
    1293
    1293
    1293
    1293
    1293
    Hook right limitation
    S2
    1893
    1893
    1893
    1893
    1893
    1893
    1893
    1893
    Main girder height
    H3
    900
    900
    1000
    1100
    1140
    1250
    1350
    1450
    Note: Control mode for ground operation.



    If you have any other questions about overhead crane, please contact us now!

    Parts Of Crane
